Description
Specifications
Operating weight52100 kg
Standard bucket7.0 m³
Maximum gross power419 kW (570 hp) @ 1600 rpm
Maximum net power398 kW (541 hp) @ 1600 rpm
Rated load12000 kg
Total cycle time14.6 s
Tipping load-full turn31200 kg
Bucket breakout force395 kN
Dump clearance, full height discharge3910 mm
Dump reach, full height discharge2050 mm
ModelCummins QSK19
EmissionsEPA Tier 3 / EU Stage IIIA
Cooling systemCharge air cooling
Length with bucket down11847 mm
Width over tires3590 mm
Cab height4195 mm
Turning radius, outside of tire7620 mm
Bucket capacity6.5-12 m³
General Purpose7.0 m³
Light material10, 12 m³
Heavy-rock6.5 m³
