Description
Operating weight10075 kg
Standard bucket1.8 m³
Gross power92 kW (125 hp) @ 2000 rpm
Net power85 kW (116 hp) @ 2000 rpm
Rated load3000 kg
Total cycle time9.7 s
Tipping load-full turn6700 kg
Bucket breakout force99 kN
Dump clearance, full height discharge2938 mm
Dump reach, full height discharge1042 mm
ModelWeichai WP6G125E221
EmissionsEPA Tier 2 / EU Stage II
Cooling systemCharge air cooling
Length with bucket down7193 mm
Width over tires2295 mm
Cab height3340 mm
Turning radius, outside of tire5090 mm
Bucket capacity1.5-3.2 m³
General Purpose1.8 m³
Light material2.5, 3.0 m³
Heavy-rock1.5 m³
