SY35U

Engine  Yanmar 3TNV88F
Rated power  18.2 kW / 2 200 rpm
Bucket capacity  0.12 m3
Operating mass  3 855 kg

Categories: ,

Description

TECHNICAL SPECIFICATIONS

THE LITTLE ONE WHO OVERCOMES BIG THINGS

Precise results and reliable high performance, getting down to work even in confined spaces – the SY35U offers everything you expect from a mini excavator. It is robust, easy to use and, thanks to its excellent performance data, suitable for all types of excavation work.

DIMENSIONS
Operating mass 3 860 kg
Standard bucket capacity 0.12
Transport length 4 915 mm
Transport width 1 720 mm
Height over cabin/ROPS 2 515 mm
ENGINE
Rated power 18.2 kW 2 200 rpm
WORKING AREA
Max. digging depth 3 105 mm
Max. digging reach 5 465 mm
Min. swing radius 2 475 mm
Bucket digging force ISO 30.4 kN
Arm digging force ISO 18.2 kN
HYDRAULIC SYSTEM
Max. oilflow 88 l/min
