| Category | Item | Unit | Parameter |
| Dimensions | Dimensions (length×width×height) | mm | 13900×2800×3675 |
| Wheel base | mm | 1470+4300+1350 |
| Track(Front/ Rear ) | mm | 2314/2314/2063/2063 |
| Front/ Rear overhang | mm | 2380/2150 |
| Weight | Front/ Rear extension | mm | 2250/0 |
| Total vehicle mass in travel configuration | kg | 42700 |
| Axle load | 1st axle | kg | 8585 |
| 2nd axle | kg | 8585 |
| 3rd axle | kg | 12765 |
| 4th axle | kg | 12765 |
| Power | Engine model | | D10.38-50 |
| Engine rated power/rpm | kW/(r/min) | 276/2000 |
| Max. net power/rpm | kW/(r/min) | 274/2000 |
| Max. output torque/rpm | N.m/(r/min) | 1560/1200-1500 |
| Travel | Max. travel speed | km/h | ≥90 |
| Min. stable travel speed | km/h | 2.5~3 |
| Min. turning diameter | m | ≤24 |
| Min. turning diameter at boom tip | m | ≤29 |
| Min. ground clearance | mm | 303.5 |
| Approach angle | ° | 19 |
| Departure angle | ° | 14 |
| Braking distance (at 30 km/h ) | m | ≤10 |
| Max. grade ability | % | ≥45 |
| Fuel consumption per 100 km | L | 40 |
| Noise | Exterior noise level | dB(A) | ≤88 |
| Noise level at seated position | dB(A) | ≤90 |
| Main performance | Max. total rated lifting capacity | t | 55 |
| Min. rated working radius | m | 3 |
| Turning radius at turntable tail | Counterweight | mm | 3625 |
| Auxiliary winch | mm | 3780 |
| Max. load moment | Base boom | kN.m | 2033 |
| Fully-extended boom | kN.m | 1225 |
| Fully-extended boom + Jib | kN.m | 624 |
| Outrigger span | Longitudinal | m | 6.1 |
| Lateral | m | 7.1 |
| Hoist height | Base boom | m | 11.9 |
| Fully-extended boom | m | 44.5 |
| Fully-extended boom + Jib | m | 60.3 |
| Boom length | Base boom | m | 11.6 |
| Fully-extended boom | m | 44.5 |
| Fully-extended boom + Jib | m | 60.5 |
| Jib offset angle | ° | 0, 15, 30 |
| Working speed | Boom raising time | s | ≤50 |
| Boom fully extended time | s | ≤100 |
| Max. slewing speed | r/min | ≥1.6 |
