Operating weight:5400-5800 kg
Rated power:55 kW
Rated operating load:1000 kg



Operating weight5470 kg
Standard bucket0.8 m³
Gross power55 kW (75 hp) @ 2400 rpm
Net power50 kW (68 hp) @ 2400 rpm
Rated load1000 kg
Total cycle time8.2 s
Tipping load-full turn3300 kg
Bucket breakout force60 kN
Dump clearance, full height discharge2420 mm
Dump reach, full height discharge790 mm
ModelLuochai YT4A2 – 24
EmissionsEPA Tier 2 / EU Stage II
Cooling systemCharge air cooling
Length with bucket down5460 mm
Width over tires1940 mm
Cab height2865 mm
Turning radius, outside of tire4185 mm
Bucket capacity0.8-1.2 m³
General Purpose0.8 m³
Light material0.8-1.5 m³
